WireGold-Maria

WireGold

Wire Golang Guard = WireGold

English | [中文](README_ZH.md)
## Overview WireGold is a pure Go Layer 3 VPN inspired by WireGuard. ### Features - **Encryption**: XChaCha20-Poly1305 (AEAD) + Curve25519 key exchange + BLAKE2B integrity check - **Transport**: UDP / UDP-Lite / TCP / Raw IP / ICMP - **Encoding**: Optional Base16384 encoding to traverse text-only filters - **Anti-censorship**: XOR mask header obfuscation + randomized MTU scaling + optional double-send - **Compression**: Optional Zstd payload compression - **NAT traversal**: Built-in Hello/Query/Notify protocol for keepalive and hole punching - **Routing**: Multi-hop forwarding with TTL decrement and routing table management - **Key rotation**: 32 preshared key slots with random index selection per packet ## Usage > On Windows, place the `wintun.dll` matching your architecture (from `lower/wintun/`) alongside the executable. > For high-latency lossy links, consider pairing with [UDPspeeder](https://github.com/wangyu-/UDPspeeder). ```bash wg [-c config.yaml] [-d|w] [-g] [-h] [-p] [-l log.txt] ``` #### Flags ```bash -c string specify conf file (default "config.yaml") -d print debug logs -g generate key pair -h display this help -l string write log to file (default "-") -p show my publickey -pg generate preshared key -w only show logs above warn level ``` ## Configuration - **macOS Mojave**: max MTU (IPv4 endpoint) is `9159` - **IPv6 endpoint**: recommended MTU `1280–1500` to avoid oversized segment drops - **ICMP / Raw IP endpoint**: use bare IP address without port (e.g. `0.0.0.0`), requires root/admin privileges ```yaml IP: 192.168.233.1 SubNet: 192.168.233.0/24 PrivateKey: 暲菉斂狧污爉窫擸紈卆帞蔩慈睠庮扝憚瞼縀 Network: udp # udp (default), udplite, tcp, ip, icmp EndPoint: 0.0.0.0:56789 MTU: 1504 SpeedLoop: 4096 MaxTTL: 64 Mask: 0x1234567890abcdef Base14: true Peers: - IP: "192.168.233.2" PublicKey: 徯萃嵾爻燸攗窍褃冔蒔犡緇袿屿組待族砇嘀 PresharedKey: 瀸敀爅崾嘊嵜紼樴稍毯攣矐訷蟷扛嬋庩崛昀 EndPoint: 1.2.3.4:56789 AllowedIPs: ["192.168.233.2/32", "x192.168.233.3/32"] # accept packets from 192.168.233.3, but don not create route KeepAliveSeconds: 0 QueryList: ["192.168.233.3"] MTU: 1400 MTURandomRange: 128 UseZstd: true QuerySeconds: 10 AllowTrans: true - IP: "192.168.233.3" PublicKey: 牢喨粷詸衭譛浾蘹櫠砙杹蟫瑳叩刋橋経挵蘀 PresharedKey: 竅琚喫従痸告烈兇厕趭萨假蔛瀇譄施烸蝫瘀 EndPoint: "" AllowedIPs: ["192.168.233.3/32", "y192.168.66.1/32"] # add route to 192.168.66.1 into inner route table but do not add it to system one MTU: 752 DoublePacket: true KeepAliveSeconds: 0 AllowTrans: false ``` ### Configuration Reference | Field | Description | |-------|-------------| | `Network` | Transport protocol: `udp` (default), `udplite`, `tcp`, `ip`, `icmp` | | `MaxTTL` | Initial TTL for outgoing packets; default `64` | | `SpeedLoop` | Log receive throughput statistics every N packets; default `4096` | | `AllowedIPs` | Prefix `x` to accept packets from the subnet without creating a system route; prefix `y` to add an internal route table entry only | | `Mask` | XOR mask for header obfuscation | | `Base14` | Enable Base16384 encoding | | `MTURandomRange` | Randomly shrink MTU by up to this value (never grows), adding traffic fingerprint randomness | | `DoublePacket` | Send every packet twice to counter heavy packet loss | | `KeepAliveSeconds` | NAT keepalive interval in seconds; 0 disables keepalive | | `QueryList` | Peer IPs to query for NAT traversal | | `UseZstd` | Enable Zstd compression | | `AllowTrans` | Allow this peer to relay traffic for other peers | ## Benchmark (localhost) > MacBook Air M1, battery mode
UDP MTU 4096 ``` goos: darwin goarch: arm64 pkg: github.com/fumiama/WireGold/upper/services/tunnel cpu: Apple M1 BenchmarkTunnelUDP/1024-plain-nob14-8 4938 228283 ns/op 4.49 MB/s 3642671 B/op 149 allocs/op BenchmarkTunnelUDP/1024-normal-nob14-8 5100 234118 ns/op 4.37 MB/s 3642409 B/op 147 allocs/op BenchmarkTunnelUDP/1024-plain-b14-8 4528 249429 ns/op 4.11 MB/s 3825461 B/op 179 allocs/op BenchmarkTunnelUDP/1024-normal-b14-8 4885 242048 ns/op 4.23 MB/s 3818262 B/op 175 allocs/op BenchmarkTunnelUDP/1024-preshared-nob14-8 4833 242460 ns/op 4.22 MB/s 3632537 B/op 144 allocs/op BenchmarkTunnelUDP/1024-preshared-b14-8 4348 239630 ns/op 4.27 MB/s 3820118 B/op 174 allocs/op BenchmarkTunnelUDP/2048-plain-nob14-8 4766 280419 ns/op 7.30 MB/s 3656588 B/op 148 allocs/op BenchmarkTunnelUDP/2048-normal-nob14-8 4353 250150 ns/op 8.19 MB/s 3639053 B/op 145 allocs/op BenchmarkTunnelUDP/2048-plain-b14-8 4136 278223 ns/op 7.36 MB/s 3848032 B/op 178 allocs/op BenchmarkTunnelUDP/2048-normal-b14-8 4264 268694 ns/op 7.62 MB/s 3842609 B/op 176 allocs/op BenchmarkTunnelUDP/2048-preshared-nob14-8 4154 262575 ns/op 7.80 MB/s 3640443 B/op 144 allocs/op BenchmarkTunnelUDP/2048-preshared-b14-8 3932 287082 ns/op 7.13 MB/s 3846167 B/op 176 allocs/op BenchmarkTunnelUDP/3072-plain-nob14-8 4006 267281 ns/op 11.49 MB/s 3690985 B/op 164 allocs/op BenchmarkTunnelUDP/3072-normal-nob14-8 3942 271832 ns/op 11.30 MB/s 3670827 B/op 162 allocs/op BenchmarkTunnelUDP/3072-plain-b14-8 3529 291120 ns/op 10.55 MB/s 3993371 B/op 211 allocs/op BenchmarkTunnelUDP/3072-normal-b14-8 3614 298778 ns/op 10.28 MB/s 3994267 B/op 211 allocs/op BenchmarkTunnelUDP/3072-preshared-nob14-8 4036 297819 ns/op 10.31 MB/s 3674026 B/op 162 allocs/op BenchmarkTunnelUDP/3072-preshared-b14-8 3705 300820 ns/op 10.21 MB/s 3989965 B/op 210 allocs/op BenchmarkTunnelUDP/4096-plain-nob14-8 2604 398308 ns/op 10.28 MB/s 7389986 B/op 320 allocs/op BenchmarkTunnelUDP/4096-normal-nob14-8 2744 399739 ns/op 10.25 MB/s 7348911 B/op 316 allocs/op BenchmarkTunnelUDP/4096-plain-b14-8 2788 430813 ns/op 9.51 MB/s 7965100 B/op 410 allocs/op BenchmarkTunnelUDP/4096-normal-b14-8 2620 432984 ns/op 9.46 MB/s 7957374 B/op 407 allocs/op BenchmarkTunnelUDP/4096-preshared-nob14-8 2750 395736 ns/op 10.35 MB/s 7348747 B/op 315 allocs/op BenchmarkTunnelUDP/4096-preshared-b14-8 2628 431785 ns/op 9.49 MB/s 7961597 B/op 407 allocs/op ```
UDP MTU 1024 ``` goos: darwin goarch: arm64 pkg: github.com/fumiama/WireGold/upper/services/tunnel cpu: Apple M1 BenchmarkTunnelUDPSmallMTU/1024-plain-nob14-8 4770 256794 ns/op 3.99 MB/s 3715458 B/op 193 allocs/op BenchmarkTunnelUDPSmallMTU/1024-normal-nob14-8 4945 242538 ns/op 4.22 MB/s 3681420 B/op 188 allocs/op BenchmarkTunnelUDPSmallMTU/1024-plain-b14-8 4137 269202 ns/op 3.80 MB/s 4101089 B/op 254 allocs/op BenchmarkTunnelUDPSmallMTU/1024-normal-b14-8 4592 253461 ns/op 4.04 MB/s 4109262 B/op 253 allocs/op BenchmarkTunnelUDPSmallMTU/1024-preshared-nob14-8 4764 243752 ns/op 4.20 MB/s 3675691 B/op 186 allocs/op BenchmarkTunnelUDPSmallMTU/1024-preshared-b14-8 4086 282682 ns/op 3.62 MB/s 4107240 B/op 253 allocs/op BenchmarkTunnelUDPSmallMTU/2048-plain-nob14-8 4728 252759 ns/op 8.10 MB/s 3762231 B/op 234 allocs/op BenchmarkTunnelUDPSmallMTU/2048-normal-nob14-8 4245 257036 ns/op 7.97 MB/s 3729842 B/op 232 allocs/op BenchmarkTunnelUDPSmallMTU/2048-plain-b14-8 3615 308642 ns/op 6.64 MB/s 4469625 B/op 342 allocs/op BenchmarkTunnelUDPSmallMTU/2048-normal-b14-8 3624 311780 ns/op 6.57 MB/s 4487346 B/op 345 allocs/op BenchmarkTunnelUDPSmallMTU/2048-preshared-nob14-8 3999 260043 ns/op 7.88 MB/s 3723444 B/op 231 allocs/op BenchmarkTunnelUDPSmallMTU/2048-preshared-b14-8 3558 315744 ns/op 6.49 MB/s 4476565 B/op 343 allocs/op BenchmarkTunnelUDPSmallMTU/3072-plain-nob14-8 3814 265654 ns/op 11.56 MB/s 3802900 B/op 280 allocs/op BenchmarkTunnelUDPSmallMTU/3072-normal-nob14-8 4380 291992 ns/op 10.52 MB/s 3760254 B/op 276 allocs/op BenchmarkTunnelUDPSmallMTU/3072-plain-b14-8 3340 338760 ns/op 9.07 MB/s 4849826 B/op 434 allocs/op BenchmarkTunnelUDPSmallMTU/3072-normal-b14-8 3302 345620 ns/op 8.89 MB/s 4852322 B/op 434 allocs/op BenchmarkTunnelUDPSmallMTU/3072-preshared-nob14-8 4424 265290 ns/op 11.58 MB/s 3761816 B/op 277 allocs/op BenchmarkTunnelUDPSmallMTU/3072-preshared-b14-8 3148 344490 ns/op 8.92 MB/s 4849613 B/op 434 allocs/op BenchmarkTunnelUDPSmallMTU/4096-plain-nob14-8 2586 399489 ns/op 10.25 MB/s 7570823 B/op 467 allocs/op BenchmarkTunnelUDPSmallMTU/4096-normal-nob14-8 2576 402297 ns/op 10.18 MB/s 7504731 B/op 464 allocs/op BenchmarkTunnelUDPSmallMTU/4096-plain-b14-8 2240 484812 ns/op 8.45 MB/s 9081331 B/op 696 allocs/op BenchmarkTunnelUDPSmallMTU/4096-normal-b14-8 2240 504749 ns/op 8.11 MB/s 9069168 B/op 693 allocs/op BenchmarkTunnelUDPSmallMTU/4096-preshared-nob14-8 2594 392716 ns/op 10.43 MB/s 7480678 B/op 460 allocs/op BenchmarkTunnelUDPSmallMTU/4096-preshared-b14-8 2234 506134 ns/op 8.09 MB/s 9066223 B/op 691 allocs/op ```
TCP MTU 4096 ``` goos: darwin goarch: arm64 pkg: github.com/fumiama/WireGold/upper/services/tunnel cpu: Apple M1 BenchmarkTunnelTCP/1024-plain-nob14-8 4627 246837 ns/op 4.15 MB/s 3684040 B/op 201 allocs/op BenchmarkTunnelTCP/1024-normal-nob14-8 4833 257150 ns/op 3.98 MB/s 3682260 B/op 199 allocs/op BenchmarkTunnelTCP/1024-plain-b14-8 4396 272838 ns/op 3.75 MB/s 3850134 B/op 231 allocs/op BenchmarkTunnelTCP/1024-normal-b14-8 4104 252293 ns/op 4.06 MB/s 3844674 B/op 226 allocs/op BenchmarkTunnelTCP/1024-preshared-nob14-8 4530 264767 ns/op 3.87 MB/s 3680243 B/op 197 allocs/op BenchmarkTunnelTCP/1024-preshared-b14-8 4231 287111 ns/op 3.57 MB/s 3847164 B/op 227 allocs/op BenchmarkTunnelTCP/2048-plain-nob14-8 4275 276425 ns/op 7.41 MB/s 3698728 B/op 200 allocs/op BenchmarkTunnelTCP/2048-normal-nob14-8 4033 261234 ns/op 7.84 MB/s 3701433 B/op 200 allocs/op BenchmarkTunnelTCP/2048-plain-b14-8 3680 303246 ns/op 6.75 MB/s 3875541 B/op 231 allocs/op BenchmarkTunnelTCP/2048-normal-b14-8 3626 288219 ns/op 7.11 MB/s 3878505 B/op 230 allocs/op BenchmarkTunnelTCP/2048-preshared-nob14-8 3868 287679 ns/op 7.12 MB/s 3696931 B/op 200 allocs/op BenchmarkTunnelTCP/2048-preshared-b14-8 3586 305008 ns/op 6.71 MB/s 3878416 B/op 230 allocs/op BenchmarkTunnelTCP/3072-plain-nob14-8 3666 298452 ns/op 10.29 MB/s 3767509 B/op 246 allocs/op BenchmarkTunnelTCP/3072-normal-nob14-8 3450 304848 ns/op 10.08 MB/s 3761811 B/op 246 allocs/op BenchmarkTunnelTCP/3072-plain-b14-8 3549 315641 ns/op 9.73 MB/s 4032830 B/op 291 allocs/op BenchmarkTunnelTCP/3072-normal-b14-8 3440 327234 ns/op 9.39 MB/s 4038470 B/op 292 allocs/op BenchmarkTunnelTCP/3072-preshared-nob14-8 3522 302663 ns/op 10.15 MB/s 3760304 B/op 245 allocs/op BenchmarkTunnelTCP/3072-preshared-b14-8 3390 326384 ns/op 9.41 MB/s 4040489 B/op 293 allocs/op BenchmarkTunnelTCP/4096-plain-nob14-8 2431 435457 ns/op 9.41 MB/s 7515476 B/op 480 allocs/op BenchmarkTunnelTCP/4096-normal-nob14-8 2500 433178 ns/op 9.46 MB/s 7511114 B/op 478 allocs/op BenchmarkTunnelTCP/4096-plain-b14-8 2337 457177 ns/op 8.96 MB/s 8033760 B/op 568 allocs/op BenchmarkTunnelTCP/4096-normal-b14-8 2374 465704 ns/op 8.80 MB/s 8040812 B/op 567 allocs/op BenchmarkTunnelTCP/4096-preshared-nob14-8 2532 436310 ns/op 9.39 MB/s 7510565 B/op 477 allocs/op BenchmarkTunnelTCP/4096-preshared-b14-8 2360 459261 ns/op 8.92 MB/s 8037878 B/op 566 allocs/op ```
TCP MTU 1024 ``` goos: darwin goarch: arm64 pkg: github.com/fumiama/WireGold/upper/services/tunnel cpu: Apple M1 BenchmarkTunnelTCPSmallMTU/1024-plain-nob14-8 3318 312084 ns/op 3.28 MB/s 3797015 B/op 307 allocs/op BenchmarkTunnelTCPSmallMTU/1024-normal-nob14-8 4102 303641 ns/op 3.37 MB/s 3795618 B/op 308 allocs/op BenchmarkTunnelTCPSmallMTU/1024-plain-b14-8 3746 314102 ns/op 3.26 MB/s 4147318 B/op 368 allocs/op BenchmarkTunnelTCPSmallMTU/1024-normal-b14-8 3609 315252 ns/op 3.25 MB/s 4152014 B/op 368 allocs/op BenchmarkTunnelTCPSmallMTU/1024-preshared-nob14-8 3826 300693 ns/op 3.41 MB/s 3793725 B/op 304 allocs/op BenchmarkTunnelTCPSmallMTU/1024-preshared-b14-8 3628 327852 ns/op 3.12 MB/s 4150869 B/op 367 allocs/op BenchmarkTunnelTCPSmallMTU/2048-plain-nob14-8 3553 315709 ns/op 6.49 MB/s 3945193 B/op 426 allocs/op BenchmarkTunnelTCPSmallMTU/2048-normal-nob14-8 3254 329794 ns/op 6.21 MB/s 3933224 B/op 427 allocs/op BenchmarkTunnelTCPSmallMTU/2048-plain-b14-8 3222 357250 ns/op 5.73 MB/s 4538189 B/op 529 allocs/op BenchmarkTunnelTCPSmallMTU/2048-normal-b14-8 3080 359401 ns/op 5.70 MB/s 4555108 B/op 535 allocs/op BenchmarkTunnelTCPSmallMTU/2048-preshared-nob14-8 3463 320078 ns/op 6.40 MB/s 3936771 B/op 426 allocs/op BenchmarkTunnelTCPSmallMTU/2048-preshared-b14-8 2990 363645 ns/op 5.63 MB/s 4555897 B/op 535 allocs/op BenchmarkTunnelTCPSmallMTU/3072-plain-nob14-8 3228 336736 ns/op 9.12 MB/s 4090750 B/op 550 allocs/op BenchmarkTunnelTCPSmallMTU/3072-normal-nob14-8 3076 347067 ns/op 8.85 MB/s 4084480 B/op 554 allocs/op BenchmarkTunnelTCPSmallMTU/3072-plain-b14-8 2798 395353 ns/op 7.77 MB/s 4952186 B/op 700 allocs/op BenchmarkTunnelTCPSmallMTU/3072-normal-b14-8 2725 403959 ns/op 7.60 MB/s 4965324 B/op 705 allocs/op BenchmarkTunnelTCPSmallMTU/3072-preshared-nob14-8 3366 344086 ns/op 8.93 MB/s 4080821 B/op 549 allocs/op BenchmarkTunnelTCPSmallMTU/3072-preshared-b14-8 2797 403142 ns/op 7.62 MB/s 4962100 B/op 703 allocs/op BenchmarkTunnelTCPSmallMTU/4096-plain-nob14-8 2360 490867 ns/op 8.34 MB/s 7940290 B/op 871 allocs/op BenchmarkTunnelTCPSmallMTU/4096-normal-nob14-8 2223 486839 ns/op 8.41 MB/s 7927235 B/op 872 allocs/op BenchmarkTunnelTCPSmallMTU/4096-plain-b14-8 2002 557560 ns/op 7.35 MB/s 9201342 B/op 1087 allocs/op BenchmarkTunnelTCPSmallMTU/4096-normal-b14-8 1868 564007 ns/op 7.26 MB/s 9216972 B/op 1091 allocs/op BenchmarkTunnelTCPSmallMTU/4096-preshared-nob14-8 2263 491698 ns/op 8.33 MB/s 7925404 B/op 869 allocs/op BenchmarkTunnelTCPSmallMTU/4096-preshared-b14-8 2050 559663 ns/op 7.32 MB/s 9211292 B/op 1086 allocs/op ```
